12bit Sensor Board Measurement Tools Angle Measurement Sensor Magnetic Induction Magnetic Encoder

Label:Yes SCL: IIC The clock line communication Package includes:1Pc Magnetic Encoder (other accessories demo in the picture is not included.) GPO: Mode selection (internal ground traction = Programming mode B ) VCC: 3.3 V GND: Feed ground SDA: IIC Data communication line DIR: Direction of rotation (earth = The value increases clockwise; then VCC = The values clockwise are reduced) Out: PWM / Analog Output Voltage Feature: 100% brand new and high quality Non-contact magnetic induction angle measurement module. High precision, a variety of output modes: IIC , PWM and voltage. Note: Due to the light and screen setting difference, the item s color may be slightly different from the pictures. Please allow slight dimension difference due to different manual measurement.
