12X11 FFT Music Spectrum Sound Control LED Spectrum Analyzer DIY Dot Matrix Electronic Production Kit

Description: Working voltage: 5V With fixed mounting holes Board size: 95 X 62 mm Display chip with audio spectrum display, built-in multiple decoding algorithms No need for filtering circuits, driving points, spectrum indications and many other indicators. FFT201211 working mode selection, users can set functions as needed Supports LED display of 12 * 11 (12 rows and 11 columns); Single (12 * 11) two-channel (left 6 * 11, right 6 * 11) dot matrix LED display 12 * 11 large dot matrix (132 points) display, multiple display mode selection Mono mode of operation can display more spectrum information Designed for audio equipment, it is used in all types of audio output equipment; Professional audio decoding, showing the frequency and amplitude of the audio signal; Three display modes (flash, slow flash 1 and slow flash 2) to provide a cool visual experience; Three sensitivity modes (high, medium, low sensitivity) are selected to suit different power supply environments; Display refresh rate 1-4 refresh speed adjustment Automatic audio gain adjustment, always showing visual effects; Circuit test mode to meet test needs during production The design circuit is simple, the performance is stable and reliable, and the current limiting resistor is directly driven to drive the LED. Memory function, can permanently maintain the parameters set by the user (There is no 3.5MM power cable docking audio cable, please purchase separately, this connection does not include) The board has a 3.5MM audio port, which can be connected to the mobile phone MP3 MP4 IPAD iPhone can be output to this with the 3.5MM audio output port, to achieve the audio spectrum function (follow the music dance)... Display function settings: Channel selection Left and right channel display position Display refresh rate setting Sensitivity setting Sampling frequency setting Audio spectrum arrangement Calculation speed method selection Numbering Name Model Quantity R7 R9-19 Resistor 33 14 R3 R6 Resistor 10 2 R1 R2 R4 R5 R8 Resistor 330k 5 C5 C6 C9-C12 C14 Capacitor 106 7 C1-C4 C7 C8 C13 Capacitor 104 7 U1 Chip fft201211 1 D1-D64 LED 144 e1 Tact switch 1 J1 J2 3.5MM patch audio port 2 DC 3.5MM DC power socket 1 PCB board 1 Total number of component parts 185 Package included: 1 x 12X11 FFT Music Spectrum DIY Kit
