10pcs OPT101 Illumination Sensor Light Intensity Sensor Module Monolithic Photodiode

Feature The OPT101 is an illuminance photosensor that integrates a photodiode and a specially optimized op amp The transparent package allows the photodiode to have a larger sensing surface with higher sensitivity and a wide spectral response range infrared to visible light 300nm 1000nm Parameter Working voltage 2 7 36VWorking temperature 0C 70CPhotodiode light irradiation area 5 2mm2Photocurrent 0 45A W 650nm Output voltage ratio 0 45V uWAnalog voltage output range Vs 1 15Bandwidth 14KHzStatic power consumption 120uA PIN Description VCC power supply positive pin V negative supply IN the inverting input of the internal op amp and the negative of the internal photodiode Do not connect or apply feedback that is abandoned in the operation1M Internal 1M feedback resistor inputOUT Amplifier outputCOM Internal photodiode positive generally connected to GNDNote The module does not solder the CEXT external capacitor and the REXT external resistor leaving the pad for easy extension Package includes 10 x OPT101 Illumination Sensor
