10pcs JDY-10 bluetooth 4.0 Module BLE bluetooth Serial Port Module Compatible With CC2541 Slave

Description: Model: JDY-10 bluetooth 4.0 slave module Kernel: M0 Communication interface: serial port Working voltage: 1.9-3.6V Communication distance: 100 meters Working current: 90ua Suspen mode: 14 uA Module is: bluetooth 4.0 slave JDY-10 transparent transmission module is based on bluetooth 4.0 protocol standard, working frequency range is 2.4GHZ range, modulation mode is GFSK, maximum transmission power is 8db, maximum transmission distance is 80 meters, low power consumption, small size, strong signal, data transmission Stable and other characteristics. Features: 1: Support Android, IOS mobile phone data penetration 2: Support low power consumption (standby current can reach several uA) 3: Support GPIO and UART peripheral interface 4: Support AT command operation 5: Can be certified by FCC/CE and other standards Product application range: 1: bluetooth LED lighting 2: Motor adjustment and other products 3: Anti-lost alarm and other products 4: Sports Health Care 5: Small appliances 6: Automotive Electronics Technical specifications: Type Specifications Working voltage 1.9 3.6V Operating temperature -40 - 85C Maximum transmit power +8dbm Antenna PCB onboard antenna Receiving sensitivity -92dbm Average current Wake mode 90uA Suspen mode 14 uA Deep Sleep mode 1uA Factory default configuration: Service UUID: FFE0 Feature UUID: FFE1 Serial port baud rate: 115200bps AT instruction set: Users can communicate with the bluetooth chip through the serial port. The serial port uses Tx, Rx two signal lines, and the baud rate is supported. Hold 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200. The default baud rate of the serial port is 115200bps. Instruction set details: (Note: You must enter and enter the line when you send the AT command. The AT command can only take effect when the module is not connected. Once the blue is enabled. When the tooth module is connected to the device, the bluetooth module enters the data transparent transmission mode) Detailed instructions: (AT commands are case sensitive and end with carriage return, newline characters: rn) 1. Get the version number: command response parameter AT+VER + Param: version Default: +JDY-10-V1.8 2. Get the bluetooth MA C address: command response parameter AT+MA C +MA C: Param: MA C address 3. Set the bluetooth name: command response parameter AT+NAME OK Param: bluetooth name Default name: JDY-10 Up to 18 bytes 4. Set / query - transmit power: command response parameter AT+POWE AT+POWE OK +POWE: Param: (0-5) 0: 8db 1: 5db 2: 0db 3:-5db 4: -10db 5: -13db 5. Set / query - serial port baud rate: command response parameter AT+BAUD OK Param: (0-7) 0: 115200 bps 1: 57600 bps 2: 38400 bps 3: 19200 bps 4: 14400 bps 5: 9600 bps 6: 4800 bps 7: 2400 bps AT+BAUD +BAUD: 6. Set / query - broadcast interval: command response Parameter AT+ADVINT OK Param:(0-6) 0: 100ms 1: 100ms 2: 250ms 3: 500ms 4: 1600ms 5: 3200ms 6: 4800ms AT+ADVINT +ADVINT: Package included: 10 x JDY-10 bluetooth 4.0 Module
