1.3 Inch 4Pin White OLED LCD Display 12864 IIC I2C Interface Module

File download Click to openFeature Resolution 128 64Control chip SSH1106Display area 29 42 x 14 7mmDriving voltage 3 3 5VOperating temperature 40 ℃ to 70 ℃Interface type IIC I2CinterfacePin definitions 1 GND power ground 2 VCC positive power supply 3 SCL clock line 4 SDA data line About control chip SSH1106 SSG1106 compatible with SSD1306 basic difference is that SSH1106 control chip RAM space is 132 64 while SSD1306 space is 128 64 The 1 3 inch OLED 128 64 dot matrix so in the middle of the screen production took 128 row When using SSD1306 program point SSH1106 screen only need to change address to 0x02 row to start Package includes 1 x 1 3 Inch White OLED Module
