Serial to WiFi Module Embedded Serial-to-Ethernet Dual Port Wireless WiFi 232 D2

Feature: Item Index Description Wireless parameter Standard certification FCC/CE/ROHS/TELEC Wireless standard 802.11 b/g/n Frequency Range 2.412GHZ-2.484GHZ 802.11b: +20dBm (Max.) Transmit power B02.11g: +18dBm (Max.) 802.11n: +15dBm (Max.) B02.11b:-89 dBm Receiving sensitivity B02.11g:-81dBm 802.11n:-71dBm Antenna Built-in antenna UART: 300bps-460800bps Hardware parameter Data interface Ethernet: 100Mbps GPIOs Operating Voltage 3.3V(+/-5%) Working current 170mA ~300mA Operating temperature -40C- 85C Storage temperature -40C- 125C Size 32mm x 45mm x8mm Software parameter Wireless network type Station/AP mode Security Mechanism WEP/WPA-PSK/WPA2-PSK Encryption type WEP64/WEP128/TKIP/AES Operating mode Transparent transmission mode, serial command mode Setting command AT+ command structure Network protocol TCP/UDP/ARP/ICMP/DHCP/DNS/HTTP Maximum number of TCP connections 32 User configuration Web server + AT command configuration Package includes: 1 x Module
