Sennheiser SK 100 G4 Bodypack Transmitter, A1: 470 - 516 MHz
Robust bodypack transmitter for daily use on stage with evolution wireless G4 100 G4 systems. Architech's SpecificationThe compact bodypack transmitter is for use with a companion receiver as part of a wireless RF transmission system. The transmitter operates within twelve UHF frequency ranges, with a switching bandwidth of up to 42 MHz: 470 - 516 MHz, 516 - 558 MHz, 520 - 558 MHz, 566 - 608 MHz, 606 - 648 MHz, 626 - 668 MHz, 734 - 776 MHz, 780 - 822 MHz, 823 - 865 MHz, 806 - 810 MHz, 925 - 937.5 MHz, 1785 - 1800 MHz; transmission frequencies shall be 1,680 per range and shall be tunable in 25 kHz steps. The transmitter features 20 fixed frequency banks with up to 12 compatible frequency presets and 1 user bank with up to 12 user programmable frequencies. The transmitter is menu-driven with a backlit LCD display showing the current frequency, frequency bank and channel number, metering of AF level, transmission status, lock status, pilot tone transmission, muting function, and battery status. An auto-lock feature is provided to prevent settings from being accidentally altered. The transmitter parameters is either configurable in the associated receiver's menu and synchronized with the transmitter via an integrated infrared interface or is programmable in the transmitter menu. The transmitter is equipped with a mute switch, which is switchable between "AF on/off", "RF on/off" and "Disabled" via the user interface.
