M5Stack® Temperature and Humidity Sensor Air Pressure Sensing DHT12 BMP280 I2C Interface

Description: ENV is a environment sensor, can be used for temperature, humidity, and atmospheric pressure measurement. Build with DHT12 and BMP280. DHT12 is a upgradation version of DHT11 humidity temperature sensor, fully downward compatible, more precise and add I2C interface. BMP280 is an absolute barometric pressure sensor especially designed for mo bile applications, offers highest flexibility to optimize the device regarding power consumption, resolution and filter performance. Feature: Temperature: measuring area: -20 ~ 60 resolution: 0.2 Humidity: measuring area: 20 ~ 95 %RH resolution: 0.1% Air pressure measuring area: 300 ~ 1100hPa resolution: 1hPa GROVE interface, support UIFlow and for Arduino Two Le go installation holes Product Size: 32.2mm x 24.2mm x 8.1mm Product weight: 4.2g Package Included: 1x ENV Unit 1x Grove Cable Related Link: Offical Video Forum EasyLoader click to download EasyLoader 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. 3.The CP210X (USB driver) needs to be installed before the EasyLoader is burned. Click here to view the driver installation tutorial Example 1. for Arduino IDE This is a ENV example, implemented reading temperature, humidity and atmospheric pressure function. 1, Before compiling, please install Adafruit BMP280 Library 2, copy Adafruit_Sensor.h to C:UsersDocumentsArduinolibrariesAdafruit_BMP280_Library The code below is incomplete. To get the complete code, please click here. /* Install Adafruit BMP280 Library first. */ #include #include "DHT12.h" #include //The DHT12 uses I2C comunication. #include #include // new two objects DHT12 dht12; Adafruit_BMP280 bme; // initialization M5.begin(); Wire.begin(); bme.begin(); // read data float tmp = dht12.readTemperature(); float hum = dht12.readHumidity(); float pressure = bme.readPressure();Copy to clipboardErrorCopied 2. UIFlow If you want the complete code, please click here. Schematic: PinMap: M5Core(GROVE A) GPIO22 GPIO21 5V GND ENV Unit SCL SDA 5V GND
