ESP8266 NodeMCU Video Remote Control + Router + Camera Kit For Chassis Tank Car

Introduction: This is a video remote control kit for tank car chassis. When getting it, you can develop a video remote control tank car chassis quickly. What's more, the connection is very easy and brief. The firmware can be seen at the following link: click here Parameters: Camera: Speed: 60frame/s Material: aluminum alloy Model: HD720p (1280*720) Type: UVC Default: 640*480 Software MAX dynamic pixels: 1600*1200 Software MAX pixel: 4000*3000 Color compress format: YUY2 (default) Interface: USB2.0,USB1.1 Distance: 30cm- Static format: BMP/JPEG Dynamic format: AVI NodeMcu: Name: ESP-12E motor shield Using ESP-12 DEV KIT development shield module Extend the output ports for ESP-12 DEV KIT: SPI,UART, GPIO, AI and 3.3V power interface Extend 2-ways motor, then can directly drive2-ways motor Design a power switch Voltage for motor: 4.5V-36V Voltage for ESP control board: 4.5V-9V Driven chip: L293DD Disparate the power of ESP board and motor for avoiding the interference. In our experiments, for convenience, a short cut module is used to connect VIN and VM for the power of ESP board and motor. Package included: 1 x Router 1 x Camera 1 x Nodemcu kit 1 x USB cable
