AVR ATMEGA16 Minimum System Development Board ATmega32 + USB ISP USBasp Programmer with Download Cable

AVR ATMEGA16 Minimum System Board ATmega32 Development Board for ISP ATTiny 51 BoardSpecifications 1 32 I O pin all the leads 2 Classic ATmega16 minimum system eliminating the hassle of soldering 3 Crystal The socket hole welding facilitate the buyer to replace the crystal 8M crystal 4 Support chips ATmega16 ATmega32 and chip which pin compatible 5 Power supply power adapter or external expansion pin power supply not support ISP download interface power supply 6 DC 005 Power Block supporting the transposon is 5 5 2 1mm 7 Expand outside 4 channel VCC GND 8 Reset Power on reset and reset button 9 Power LED D1 and the program run indicator D2 10 Standard ISP download interface 11 Size 88mmx38mm 3 47x1 49 inch approx Features 　1 This programmer is based on Thomas Fischls USBasp design and connects to your computers USB port Not only is it quite compact but the design is really elegant The USB interface is achieved by using an atmega processor and the rest is done in firmware 2 With 500mA over current protection self recovery fuse and complete protection of expensive computer motherboarddesigned for notebook computers special two 3 6V regulator a perfect match to level get rid of the instability of hardware hidden Target board power mode jumper settings 　 3 The well configured firmware the speed of the unique adaptive technology stability and obtain the best balance between speed Supports firmware upgrade unlimited Schematic me
