Tilt Sensor Module / Vibration Sensor Module Switch Microcontroller Electronic Building Blocks Smart Robot for Arduino

Specification 1 Adopt high sensitivity vibration switch the default is SW 1801P vibration sensor SW 520D Tilt Sensor Module 2 Comparator output clean signal good waveform strong driving ability more than 15mA 3 Working voltage 3 3V 5V4 Output form digital switch output 0 and 1 5 With fixing bolt holes for easy installation6 Small board PCB size 31mm x 14mm7 Use wide voltage LM393 comparatorModule instructions SW 520D1 The switch quantity output by the module depends on the turning on and off of the angle switch When the angle switch is turned off the DO outputs a high level and when the angle switch is turned on the DO outputs a low level 2 The output end can be directly connected with the single chip microcomputer and the high and low levels are detected by the single chip microcomputer thereby detecting the angle change 3 The output terminal can directly drive the relay module which can form a high power angle switch to protect the electrical equipment and other products when the power is automatically turned off SW1801P1 When the product does not vibrate the vibration switch is off the output end outputs a high level and the green indicator light is off 2 When the product vibrates the vibration switch i s turned on instantaneously the output end out puts a low level and the green indicator light is on 3 The output terminal can be directly connected with the single chip microcomputer and the high and low levels are detected by the single ch
