Sipeed Maix-GO RISC-V Dual Core 64bit Development Board Mini PC+ Wifi + Antenna + 2.8inch TFT Touch Screen + 2 Megapixel OV2640 Large Camera + USB Cable + Protective Case Kit

Characteristic: CPU : RISC-V Dual Core 64bit, with FPU, 400Mhz standard Frequence(Can be overclocked) Image Identification: QVGA@60FPS/VGA@30FPS Audio port: Support Sipeed R6+1 Microphonoe Array board with FPC10 connector and 2x3W Speaker Power management: Charging current up to 2.5A; integrated dynamic path management Download circuit: Just connect the USB typeC cable to complete the download Digital Triaxial Accelerometer Onborad MSA300 Wireless Function: Support 2.4G 802.11.b/g/n Size: After assembly: 90x 61.5 x 18.5 mm Before assembly: 90x 61.5 x 9.5 mm FEATURES OVERVIEW Master module Sipeed M1W AIOT module( Power management ETA6002(ETA6002 is a single-cell Li-Ion switch-type charging chip with a charging current of 2.5A. It integrates dynamic path management, and the internal path of the switch has an internal resistance of only 50mohm, allowing the system to remain in the adapter without the battery) Battery path and USB path can be switched automatically GPIO interface All GPIOs connected to header 2*20 2.54mm Micro SD card(TF card) slot Support Self-elastic card holder Onboard MEMS microphone MSM261S4030H0 is an omnidirectional, Bottom-ported, I 2 S digital output MEMS Microphone. It has high performance and Reliability DVP Camera interface 24P 0.5mm FPC connector LCD interface Maix-LCD board(with Resistive touch screen) is directly connected to the pin header Digital Triaxial Accelerometer User selectable range : 2g, 4g, 8g, 16g User selectable data output rate I2C interface 14 bits resolution Low power consumption RTC Onboard 32.768k crystal connected with STM32F103 Button Three-way dial switch and one Reset push button SOFTWARE FEATURES FreeRtos & Standard SDK Support FreeRtos and Standrad development kit MicroPython Support Support MicroPython on M1 Machine vision Machine vision based on convolutional neural network Machine hearing High performance microphone array processor HARDWARE FEATURES Supply voltage of external power supply 4.8V ~ 5.2V Supply current of external power supply >600mA Temperature rise
