STM32F767 Development Board Cortex-M7 Small System Board STM32F767IGT6 STM32

Description: Onboard: STM32F767IGT6 chip Core: Cortex-M7 32-bit RISC Features: Single-cycle DSP instructions; Operating frequency: up to 216MHz; Working voltage: 1.8V-3.6V; Packing: LQFP176; Storage resources: 1024kB Flash, 320kB SRAM; Resources: 6xSPI, 4xUSART, 4xUART, 3xl2S, 1xSAI, 3xl2C; 1xFMC, IxSDIO, 2xCAN; 1 x USB 2.0 FS/HS controller (with dedicated DMA); 1 x USB HS ULP (for external USB HS PHY); 1 x 10/100 Ethernet M AC; 3xAD (12bit, 1us, 24) 2xDA (12 bit); TIM timer: 10X general-purpose timer, 2X advanced timer, 2X basic timer, 1X low-power timer. Data access FLASH: W25Q128/16MB. The basic circuit of on-board MCU includes 25MHz, 32.768KHz crystal oscillator circuit, USB power management circuit and USB interface. Except for on-board SDRAM and GPIO occupied by SPI FLASH, all the pins of the I/O peripheral devices are in the form of 2.54mm pin arrays. All the resources of the chip can be freely used. With JTAG/SWD debugging and downloading interface. Four-ply process, stable performance. Working frequency: up to 180 MHz, 225 DMIPS/1.25 DMIPS/MHZ Working voltage: 1.8V-3.6V SDRAM: IS42S16400J-7TLI/8MB Package included: 1 x STM32F767 Development Board Pin Descriptions: 1. D2: Power indicator 2. RESET: Reset button 3. J6: USB interface 4. KEY: User button 5. 25MHz x 32.768MHz crystal 6. 3.3V regulator device 7. Flash: W25Q12816MB 8. 2x27 pin headers in two rows, a total of 108 pins: GPIO97, power supply and GND11 9. STM32F767IGT6 chip 10. ISP interface: - 3V3: working voltage positive - GND: Operating voltage negative - TX: module serial port send pin (ie PA9) - RX: module serial port receiving pin (ie PA10) 11: JTAG/SWD debug interface 12: D1 User LED 13: SDRAM: IS42S16400J-7TL18M
