RAT1606 Rivet Nut Tool (1/2-12MM Capacity)

This aggressively priced tool installs up to 1/2 rivet nuts using its advanced SPIN-PULL-SPIN setting sequence. The rivet nut quickly spins on when pressure is applied to the mandrill. Pull the trigger and the rivet nut is pulled and installed release the trigger and the mandrill spins out of the rivet nut. The setting cycle is about 2 seconds. The RAT1606 Rivet Nut tool has a fully adjustable stroke for accurate insert placements which requires less operator skill. Stroke adjustment (1-6MM) is quick and easy and is done using a stop nut which adjusted from the exterior. Comes equipped with UNC sizes 8-32 10-24 1/4-20 and 5/16-18 3/8-16 and 1/2-13 mandrels. Metric standard sizes 3M-.5 4M-.7 5M-.8 6M-1.0 8M-1.25 10M-1.5 & 12M-1.75 mandrills/anvils are also available but sold separately. Pneudraulic Rivet Nut Tool 0.25 Inch (6 mm) Stroke Pull Capacity: 3 600lb. at 100 psi (25kN at 7 bar) Air Pressure 70-100 psi (5-7 bar) Power Source: 70-100 psi Shop Air Hydraulic Fluid: Automatic Transmission Fluid meeting DEXRON® III DEXRON VI MERCON® Allison C-4 or equivalent 32 to 125 Deg F (0 to 51.7 Deg C) Operating Temperature Cylinder Diameter: 3.0 Inch (75mm) Overall Height: 11 Inch (280mm) Length of Head: 11 Inch (280mm) Center to Edge: 0.75 Inch (18mm) Fastener Type: 1/2 Rivet Nut Weight 4.9lb. (2.2kg)
