PWM DC Motor Governor 6V12V24V30V DC Forward and Reverse Switching Controller

Feature: Fully support 6V-30V power supply voltage motor application Achieving Zero Sound in Motor Rotation at Low Speed Solve the problem that other governors can't adjust zero or maximum Technical Parameters: Model: CCM6N potentiometer: resistance B10K; line length 20cm; opening 8mm; Operating voltage: DC6V-30V output voltage is about 0-100% of the input voltage Control power: 6V*6A=36W, 12V*6A=72W.....30V*6A=180W Rated current: 6A Maximum current: 10A Speed range: 0%-100% Size: 74 x 47 x 28mm PWM frequency: 16kHz Weight: 68g Precautions and instructions for use: 1. DC motor governor input is DC, not directly connected to AC, otherwise, it will burn out 2. The positive and negative poles of the DC power supply cannot be reversed, otherwise, the governor will be damaged. 3. The motor can be positive or negative, when the running direction is inconsistent with the expectation. The direction can be changed by the line adjustment sequence. 4. The potentiometer knob can change the governor output duty cycle to change the motor speed. Package includes: 1 x PWM DC Motor Governor
