Original JYETech DIY FG085 DDS Digital Synthesis Function Generator Unassembled Kit With Panel

Note This kit not include the power supply This kit with panel if you need no panel version please search item 974905Please click here to download the Assembly GuideFeature The output signal types sine square triangle positive and negative sawtooth positive and negative staircase user defined arbitrary waveforms and servo control signalFrequency range 0 200KHz sine Frequency resolution 1HzFrequency accuracy 0 149Hz when F 40Hz time 0 000596Hz when F 40Hz time Cycle Resolution 1msAmplitude range 0 10V ppAmplitude accuracy 0 1VDC offset range 5V 5VDC offset Accuracy 40mVWaveform memory depth 256 bytesMaximum sample rate 2 5MspsTrigger Input Level High 3 5V minimum low 1 5V maximum When the trigger waveform output delay less than 5 subtleSynchronous output TTL levelOutput Impedance 50 ohmPower supply voltage 15V DCSupply Current 150mA no load Example 1 The output frequency is set to 5KHz key operation F T 5 KHz 2 the output amplitude is set to 3V peak to peak key operation AMP 3 V 3 The DC offset is set to 2 5V key operation OFS 2 5 V The main operating modes Fixed frequency mode CW Sweep mode SWEEP Servo signal patterns SERVO Package included 1 x FG085 DDS Digital Synthesis Function Generator Kit With Panel
