M5Stack® Temperature Humidity Sensor ENV Weather Station and Compass Compatible for M5StickC ESP32 IoT Development Board Finger Computer

Description: Hat ENV It is able to detect the temperature, humidity, air pressure and magnetic field. This product relates via I2C protocol which allows you to obtain 4 types of environment data thru just 2pins, together with the tiny body, makes it a powerful application for envitonment data collecting. Product Feature: temperature: Range: -20 ~ 60 Error: 0.2 Humidity: Range: 20 ~ 95 %RH Error: 0.1% Air pressure: Range: 300 ~ 1100hPa Error: 1hPa Typical Magnetic Field: - 1300T(x,y-axis),2500T(z-axis) - magnetic field resolution: 0.3TCopy to clipboardErrorCopied Package Includes: 1x ENV Hat Application: Weather Station Compass Schematic: Links: Official Channel Official forum BMP280 library BMM150 Datasheet EasyLoader click to download EasyLoader 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. Example: Arduino Pin Map: M5StickC GPIO0 GPIO26 5V GND HAT ENV SDA SCL 5V GND
