M5Stack® ATOM PoE Ethernet Accessory Supports PoE Active Ethernet Technology Build in W5500 Ethernet Controller

M5Stack® ATOM PoE Ethernet Accessory Supports PoE Active Ethernet Technology Build in W5500 Ethernet Controller
M5Stack
sku: 1839163
$41.50+4%
$42.99
Shipping from: China
   Description
Description ATOM PoE is an Ethernet accessory for the M5 Atom series which Supports PoE Active Ethernet technology The built in PoE module can directly supply power to the entire device through a PoE hub switch without a separate power supply effectively reducing the cost of your setup It has a built in W5500 Ethernet controller integrated TCP IP protocol stack with 8 independent hardware sockets 10 100M Ethernet data link layerand physical layer PHY to provide a more convenient Internet connection solution for your embedded systems It can meet the wired network access requirements in the production environment Product Features Supports PoE IEEE802 3 AFWired Ethernet Access8 independent hardware socketsSupports TCP UDP ICMP IPv4 ARP IGMP PPPoEIntegrated 10BaseT 100Base T Ethernet PHYIncludes 1x ATOM PoE1x ATOM LITE1x TYPE C USB Cable 20cm Application Remote controlWired Internet connectionSpecification SpecificationParameterEthernet ChipW5500Supported ProtocolsTCP UDP ICMP IPv4 ARP IGMP PPPoEPoE Power SupplyIdle pin power supply 10M 100M Ethernet J4J5 VC J7J8 VC PoE SpecIEEE802 3 AFNet Weight22gGross Weight44gProduct Dimension24 48 18mmPackaging Dimension54 54 20mmRelated Links DatasheetW5500Pinout ATOMGPIO22GPIO19GPIO23GPIO33ATOM PoECLKCSMISOM0SISchematic Example 1 Arduin0Click here to download the Arduin0 example
