JHEMCU Betaflight F4-Openloger Blackbox Flight Data Recorder for F4 Flight Controller RC Drone FPV Racing

Description Prepare your own Micro SD card Connect the F4 openlager module and the flight controller correctly Refer to the wiring diagram for the connection method The BetaFlight ground station sets the port function of the external black box Here UART7 is used as a demonstration and Blackbox logging is selected and the baud rate is 2000000 Enter the black box interface and select Serial Port 2KHZ GYRO SCALED Black logging rate mode are selected according to their actual needs After each setting is completed click the Save and Restart button Indicator meaning Red light power is normalBlue light off SD card detected ready to workBlue light flashes slowly no SD cardBlue light flashes quickly it will only appear after the remote control is unlocked and the black box normally writes the data returned by the flight controllerReading of black box files Export the LOG000 file of the SD card to the computer the file serial number is automatically incremented by 1 each time the power is turned on where the CFG file is the black box configuration file this can be exported without LOG000 is the log file generated after unlocking this time It can be opened with Betaflight Blackbox Explorer software and the recorded flight data can be seen Pictures 1 6 are instructions for use Specification Brand JHEMCUPower supply 5VInterface UARTWeight 1 1gPackage Included 1 X Blackbox Flight Data Recorder
