JDS2023 Digital Storage Handheld Oscilloscope 1 Channels 20MHz Oscilloscope AC/DC Input Coupling with Signal Generator Function

JDS2023 Digital Storage Handheld Oscilloscope 1 Channels 20MHz Oscilloscope AC/DC Input Coupling with Signal Generator Function
oscilloscope
sku: 1190137
$153.00+8%
$164.98
   Description
Description: It is an electronic tool used to graphically depict sound waves and environmental frequencies. This tool is helpful in a number of different applications. Some of the most common include music, particularly radio frequencies and digital music remastering, but it can also be helpful in certain circuitry and engineering scenarios and in doing things like measuring seismic activity and certain other sounds in nature. Features: With signal generator function 200MSa/s sample rate and 20MHz bandwidth 3.2 inch color TFT LCD, 320 x 240 pixels You could switch menu language between English and Chinese Powered by 1 x 3000mAh 18650 Li-ion battery (not included) Oscilloscope Function: Input Input coupling: AC,DC Channel: 1 Display mode: Y-T The input impedance: 1M 25pF The maximum input voltage: 40V(Probe X1);400V(Probe X1);2000V(Probe X100) Probe attenuation: 1X,10X Attenuation setting: 1X,10X,100X Signal acquisition system Sampling method: Real time sampling, random sampling The storage depth: 2K Acquisition mode: Sampling, peak detect Vertical system Vertical sensitivity: 10mV-5V(Probe 1X) 100mV-50V(Probe 10X) (1,2.5,5 Stepping) The vertical accuracy: +/-3% The vertical resolution: 8bit Bandwidth: 20MHz Horizontal system The real-time sampling rate: 200 MSa/s Horizontal scanning range: 10nS/div-5S/div Triggering system Trigger Mode: Automatic, normal and single Trigger Type: The rising edge, falling edge Automatic detection: Support(50Hz-40MHz) Measurement system Cursor measurement: Support time and voltage Measuring method: Manual Measurement: The peak to peak value and frequency Equipment Screen: 3.2 inch,16 bit true color,TFT,320*240 Battery: 2000+mA Lithium battery (support 5 hours of continuous work) Size: 202 x 100 x 35mm Package weight: 1.130 kg Digital channel: 200 MSa/s Signal Generator: Frequency range: sine 1Hz - 5MHz, other waveforms 1Hz - 1MHz Duty ratio: 0 - 100 percent Amplitude: 100mV - 4V Offset: +(0V -2V) Package included: 1 x JDS2023 Digital Storage Handheld Oscilloscope 1 x Charger 1 x USB Cable 1 x Probe 1 x CD Detail Pictures:
