Hikvision DS-2CD2442FWD-IW 4MP Cube Wiresless Security Camera

Video
The DS-2CD2442FWD-IW is a cube network camera from Hikvision. WiFi connectivity for quick setup.On-board storage via Micro SD card (not included), and IR infrared LEDs for night-vision recording. It has a small, easily adjustable body, and is great for use in homes or small businesses.
Features
Up to 4.0 megapixel high resolution
Full HD 1080p video
Available in 2.8mm or 4mm lens
Up to 10m IR
PIR (Passive IR) for motion detection
120 dB WDR/3D DNR/BLC
Built-in mic and speaker
Support MicroSD up to 128GB (not included)
Built-in Wi-Fi
Specifications
Camera
Image Sensor 1/2.8" Progressive Scan CMOS
Signal System PAL/NTSC
Min. Illumination 0.01Lux @(F1.2,AGC ON), 0 Lux with IR0.028Lux @(F2.0,AGC ON), 0 Lux with IR
Shutter time 1/3 s to 1/100,000 s
Lens 2.8 mm, horizontal field of view 105.8° [ 4 mm (83°), optional]
Lens Mount M12
Day& Night IR cut filter with auto switch
Wide Dynamic Range 120 dB
Digital noise reduction 3D DNR
Compression Standard
Video Compression H.264/MJPEG
H.264 code profile BaseLine Profile/Main Profile
Video bit rate 32Kbps~8Mbps
Audio Compression G.711/G.722.1/G.726/MP2L2
Audio bit rate 64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)
Max. Image Resolution 2688 × 1520
Frame Rate 50Hz: 20fps (2688 × 1520), 25fps (1920 × 1080, 1280×720)60Hz: 20fps (2688 × 1520), 30fps (1920 × 1080, 1280×720)
Image Settings Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC Yes, zone configurable
ROI support
3D DNR support
Network
Network Storage NAS (Support NFS,SMB/CIFS)
Alarm Trigger Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface 1 RJ45 10M / 100M Ethernet interface
Alarm Input 1
Alarm Output 1
On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Wi-Fi Specification (-W)
Wireless Standards IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth 20/40MHz Support
Modulation Mode 802.11b: CCK, QPSK, BPSK802.11g/n: OFDM
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power 11b: 17±1.5dBm @ 11Mbps11g: 14±1.5dBm @ 54Mbps11n: 12.5±1.5dBm
Receive Sensitivity 11b: -90dBm @ 11Mbps (Typical)11g: -75dBm @ 54Mpbs (Typical)11n: -74dBm (Typical)
Transmission Rate 11b: 11Mbps11g: 54Mbps11n: up to 150Mbps
Wireless Range 50m(depend on environment)
Protocols IEEE802.11b, 802.11g, 802.11n
General
Operating Conditions -10 °C – 40°C (14 °F – 104 °F), Humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption Max. 5W
IR Range 10 meters
PIR Angle: 90°, Range: 8m
Dimensions 72.3 x 91.9 x 131.3 mm (2.85” × 3.62” × 5.17”)
Weight Approx. 400g (0.88lbs)
