Geekcreit® 3.5 Inch 320 X 480 TFT LCD Display Touch Board For Raspberry Pi 3 Model B RPI 2B B+

Manual and driver (please click here) ( Due to the different batch,These board have two colors, Bule or Green, will be send in random, please note that before you buy it ... ) Suitable case:1102333 Parameter: LCD Type TFT LCD Interface SPI Touch Screen Type Resistive Touch Screen Controller XPT2046 Colors 65536 Backlight LED Resolution 320*480 (Pixel) Aspect Ratio 8:5 Power Consumption TBD Backlight Current TBD Operating Temp. (Centigrade) TBD Interface Definition: PIN NO. SYMBOL DESCRIPTION 1, 17 3.3V Power positive (3.3V power input) 2, 4 5V Power positive (5V power input) 3, 5, 7, 8, 10, 12, 13, 15, 16 NC NC 6, 9, 14, 20, 25 GND Ground 11 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching 18 LCD_RS Instruction/Data Register selection 19 LCD_SI / TP_SI SPI data input of LCD/Touch Panel 21 TP_SO SPI data output of Touch Panel 22 RST Reset 23 LCD_SCK / TP_SCK SPI clock of LCD/Touch Panel 24 LCD_CS LCD chip selection, low active 26 TP_CS Touch Panel chip selection, low active Package included: 1 x 3.5 Inch 320 X 480 TFT LCD Display Touch Board
