GY-AMG8833 IR 8x8 Infrared Thermal Imager Sensor Array Temperature Measurement Sensor Module with UNO R3 GY-AM Kit

Introduction This sensor is an 8x8 thermopile array This means you have a 64 pixel square array each of which can independently detect temperature It s like having a thermal imaging camera or carnivores vision but with low resolution It is part of the Qwiic system so it is easier to connect to obtain low resolution infrared images When connected to your microcontroller or Raspberry Pi it will return a set of 64 individual infrared temperature readings via I2C It s like those fancy cameras but compact and simple for easy integration The AMG8833 is the next generation 8x8 thermal infrared sensor and provides higher performance than the previous AMG8831 The sensor only supports I2C and has a configurable interrupt pin which can be triggered when any single pixel is above or below the threshold you set The AMG8833 infrared thermal imager sensor temperature measurement range is 0 ° C to 80 ° C 32 ° F to 176 ° F with an accuracy of 2 5 ° C 4 5 ° F It can detect humans from a distance of up to 7 meters 23 feet The maximum frame rate is 10Hz which is ideal for creating your own body detector or mini thermal imager We use this breakthrough code on Arduin0 or compatible sensors communicate via I2C or Raspberry Pi using Python On the Pi with the help of the image processing of the SciPy python library we can insert an 8x8 grid and get some very good results Parameter Working voltage start 1 6V 3 6VWorking voltage timing 1 5V 3 6VCurrent consumptio
