Digital Resistance Meter 2 in 1 Insulation Resistance Test LCD Backlight Multimeter Megohmmeter Megger Voltmeter Ohm Tester
sku: 32955901010
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$46.34
Shipping from: China
Technical Details
| ACA: | 40mA/400mA±1%±5d |
| Accuracy: | 200kΩ~200MΩ±3%Ω±5d,200MΩ~4GΩ±5%±5d,4GΩ~40GΩ±10%±5d |
| ACV: | 4V/40V/400V±0.8%±5 ,700V±1%±5d |
| Auto Range: | Y |
| Brand Name: | SZBJ |
| Capacitance: | 40nF/400nF/4uF/40 uF±3%±5d |
| DCA: | 40mA/400mA±0.8%±5d |
| DCV: | 400mV/4V/40V/400V±0.5%±5d,1000V±0.8%±5d |
| Dimensions: | 170x156x64mm |
| Display Type: | Digital Only |
| DIY Supplies: | Electrical |
| Frequency: | 40Hz/400Hz/4 kHz /40 kHz/400 kHz /4MHz ±0.5%±3d |
| Insulation Resistance: | 0.5MΩ~40GΩ |
| Item Size: | 170x156x64mm |
| LCD Backlight: | Y |
| Max display: | 3999 |
| Measuemeat time: | 1/2/10min (min) |
| Measuemeat Voltage: | 500V/1000V/2500V |
| Measuring Range: | 0.5M-40G |
| Model Number: | BM3549 Digital Insulation Resistance Test Meter |
| Power: | 1.5V AA Batteries(LR6)X 6(not included) |
| Resistance: | 400Ω/4kΩ/40kΩ/400kΩ±0.8%±5d, 4MΩ±1%±3d,40MΩ±3%±3d |
| Short Circuit Current: | ≥1.5mA |
