Carving Control System Operatio Control Parameters CNC Motion Controller Engineering Technology For Industry Mechanical

Carving Control System Operatio Control Parameters CNC Motion Controller Engineering Technology for Industry Mechanical Specification: Features: Parameter setting: can set process and operation various control parameters to the optimal effect. Manual operation: can be achieved manually jog back to the program back to mechanical cleared coordinate operations. Program management: can create program delete modify read save save automatic processing continuous and pause. External Manual: Manually define a variety of external functions to facilitate the use to select the input function: input port can achieve a variety of user needs CNC system consists of the following components: 1.High-performance high-speed 32-bit ARM CPU 2.Liquid crystal display resolution: 320 x 240 display size:60x45 3.Input / Output 10MA 16 opto-isolated inputs and 16 opto-isolated output pull-down 500MA 4.Users machining program memory can be implemented in any storage memory card 5.Support Folder read each folder maximum support 50 tool files Specifications: The smallest unit of data: 0.0001mm The maximum data size: ± 99999.999mm Maximum pulse output frequency: 50KHz - simultaneous 50KHZ Control axes: 4 X Y Z A Linkage axle count: 4 linkage and four - multi - micro multi - line prospective interpolation control Weight: 611g Package includes: 1 x CNC Motion Controller 2 x Card 2 x Connection board 2 x Fixed seat Note: Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
