Beitian BN-180T GPS GLONASS Module For APM Pixhawk CC3D Naze32 F3 F4 Flight Controller RC Airplane

Description: Brand Name: Beitian Item NO.: BN-180T Item Name: GPS GLONASS Module Specifications: Electrical Characteristics Chipset M8030-KT Frequency GPS L1, GLONASS L1, BEIDOU B1, GALILEO E1, SBAS L1, QZSS L1 Receiving Format GPS, GLONASS, BEIDOU, GALILEO, SBAS, QZSS. Default GPS, GLONASS, SBAS, QZSS. Channels 72 Searching Channel Sensitivity Tracking -167dBm Reacquisition -160dBm Cold Start -148dBm Hot Start -156dBm Accuracy Position Horizontal 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky) Velocity 0.1m/sec 95% (SA off) Timing 1us synchronized to GPS time Acquisition Time Cold Start 26s Warm Start 25s Hot Start 1s Data Output Support Rate 4800bps to 921600bps, Default 9600bps Data Level TTL Level Data Protocol NMEA-0183 or UBX, Default NMEA-0183 NMEA message RMC, VTG, GGA, GSA, GSV, GLL Concurrent GNSS 1Hz-10Hz, Default 1Hz Operational Limits Altitude 50,000m Max Velocity 515m/s Max Acceleration Less than 4g Power Consumption VCC DC Voltage 3.0V-5.5V, Typical: 5.0V Current Capture 50mA@5.0V Mechanical Specifications Dimension 18mm*18mm*8mm Weight 7.9g Connector 1.00mm 4pins connector Environment Operating Temp -40 C ~ +85C Storage Temp -40C ~ +105C LED TX LED(blue) LED Flashing: Output Data PPS LED(red) PPS LED not bright when GPS not fixed, flashing when fixed Pins Definition: NO. Name I/O Description characteristic 1 GND G Ground Ground 2 TX O UART Communication Interface,TTL Level GPS Data Output 3 RX I UART Communication Interface,TTL Level GPS Data Output 4 VCC I Main Power, DC Input DC 3.0V-5.5V (Typical: 5.0V) Package Included: 1x Beitian BN-180T GPS GLONASS Module
