4A Motor Shield MC33932 Dual H-Bridge Drive Board Short Circuit Protection Two DC Motor Driver

Product Details The 4A Motor Shield is based on the Freescale MC33932 dual H Bridge Power IC which can control inductive loads with currents up to 5 0A peak per single bridge It lets you drive two DC motors with your Arduino Seeeduino board controlling the speed and direction of each one independently You can also measure the motor current absorption of each motor among other features The on board DC DC converter suport a very wide range of input voltage and can provide a 5V power supply for the microcontroller board with 100mA maximun current So you just need one power supply to drive the motors and power up the logic circuit Features Output short circuit protection short to VPWR or GND Over current limiting regulation via internal constant off time PWMTemperature dependant current limit threshold reductionDimensions115mm x75mm x25mmWeightG W 53gBatteryExcludeOperating Voltage6V 28VDC DC output5V 100mA 5V pinOutput Current For Each Channel 2A continuous operation 5A peak Output Duty RangeOutput Duty Range 0 100 Documentations Schematic pdfMotor Shield LibraryMC33932 DatasheetwikiPackage includes 1 x 4A Motor Shield
