4-20mA 0-10V Current Signal Generator Source Transmitter PLC Valve Calibration

Features: ? This is a newly developed, neatly designed, and high precision current loop simulator. Its design is based on years of experience field work calibrating work, it is reliable and considerate. ? The device is mainly used for industrial PLC, instrument calibration, electric valve calibration, etc. ? The device is easy to operate, with long stand-by time, handy, and featured by high precision. ? For recharging, we can use mobile phone or PC to charge it via its mini USB interface. ? The device has two channels of output: one channel for current and voltage output, the other channel is sensor transducer analog output. ? The analog output has two features: ? First, it can simulate transducer of 2-wire-system and 4~10mA current, e.g pressure transducer. The positive / negative of the device can be regarded as the positive/negative of a 2-wire-system transducer). ? Second, passive output function can be used for 0~24mA input. Both input and output can set range. For example, we set 0~50, which correspond to 4~20mA display. Specification: Material: Acrylonitrile Butadiene Styrene (ABS) Active current: 0~24mA output (definition 0.01mA). Max load 500 ohm. Passive current: 0~24mA output(definition 0.01mA). Max load power supply 25V. Can be used also as current input. Passive input: 0~24mA(definition 0.01mA). Voltage output: 0~10V(definition 0.01V). Inaccuracy deviation: +/- 0.01 Environment temperature: -10~50? USB power supply and recharge. Dimensions: 90 x 70 x 28 mm Product Description: 4-20mA / 0-10V Current Signal Generator Source Transmitter PLC Valve Calibration Package Included: 1 x Current Loop Simulator 1 x Pair of Banana Cables 1 x Mini USB Cable for Recharging Detail Pictures:
