3pcs 315Mhz Wireless Remote Control Switch AC 250V 110V 220V 2CH Relay Receiver Module with RF Remote Controls

Technical Data: Input Power:AC 85V-250V Standby Current: 97 dbm Decoding mode: MCU software decoding Learnable Transmitters: 1-16 transmitters Support remote type: Learning code (1527) Switching Modes: Both Momentary & Toggle Wiring type: Fixed terminal Switch Output: Normally open & normally closed. The dimension of PCB: 35*30*18mm (L*W*H) Switch Output: NO: normal open COM: common NC: normal close Wire port: NO: normal open COM: common NC: normal close Working Modes explanation: Momentary Mode: Push the remote button, the relay activates, release the remote button the relay deactivates. Toggle Mode: Push and release the remote button, the relay activates. Push and release the remote button again and the relay deactivates. Clearing All Stored Transmitters: *Note: After clearing the stored transmitters, all transmitters will need to be relearned by the receiver. Push the learning button on the receiver 8 times, and the codes will be cleared. Learning the transmitter: (momentary Mode) Programming a 2 button transmitter as momentary mode transmitter. STEP 1: Push and release the learning key on the receiver ONCE. Wait for a moment, the LED will turn off, indicating you entered the learning state. STEP 2: Push and release the first button on your transmitter, the LED on the receiver board will flash on then off indicating the button was learned. STEP 3: Press and release the second button, watching the LED go on and off again. Wait 3 seconds, the LED will turn on again, the indicating system is ready for use. Learning the transmitter : ( Toggle Mode ) Programing a 2 button transmitter as toggle. STEP 1: Press and release the learning key on the receiver TWICE. Wait for a moment, the LED will turn off, indicating you entered the learning state. STEP 2: Press and release the first button on your transmitter, the LED on the receiver board will flash on then turn off. Indicating the button was learned. STEP 3: Next press and release the second button, watching the LED go on and off again. Wait 3 seconds, the LED indicator will turn on again, indicating system is ready for use **Notice** Two-button transmitters can only be used as toggle or momentary. One mode per 2 button transmitter. (Please note: You let the control panel to learn the remote control, you must press the "A" and "B" button; Rather than just pressing one of them) However, you can program another transmitter in the other mode. Package includes: 3 x Module
